Self Made Dispensing Machine

Introduction

Self-made dispensing machine action process:
1. On-line equipment, the carrier flows into the upper end equipment to block the jacking and positioning;
2. Double Y-axis servo servo drive is used to ensure the uniform position of the large span, and the X-axis servo screw;
3. The glue bucket is The self-made glue push is the self-built servo screw module to complete the glue push and injection action, and the self-made glue stop device.

File Formats

– SolidWorks 2018 | Keyshot 10

– STEP (Standard for the Exchange of Product Data)

– IGES (Initial Graphics Exchange Specification)

– STL (Standard Tessellation Language )

– OBJ (Object Files)

Geometry

– Polygons: 1,008,856
– Vertice: 3,026,568
