Standard flanged 90° bend socket for 12 inch pipe
Modeled for ASTM and ASMI compatible engineering dimensions (Long radius, Schedule 40, Class 150)

Pipe Section
Pipe Size – 12 inch
Outside Diameter – 12.75 inch
Inside Diameter – 11.938 inch
Wall thickness – 0.406 inch
Centre to End – 18 inch (without Flange section)
Pipe Schedule No – 40

Flange Section
Flange Outside Diameter – 19.00 inch
Flange Thickness – 1.19 inch
Bolt Circle Diameter – 17.0 inch
Diameter of Holes – 1.00 inch
Number of Holes – 12 (per flange)

Poly/Vert Details
Poly without Turbosmooth - 1,416
Vert without Turbosmooth - 1,392
Poly with 2 Turbosmooth iterations - 45,696
Vert with 2 Turbosmooth iterations - 22,800

Material – Vray

3D Max file content model with TurboShooth modifier, and the other file types having the model without modifier

Other types of sockets (45° bends, 60° bends, return bends, straight sections, Tees, Etc.) also available with different sizes
